Toshiba B2004FLF4BSH01
Toshiba EQP Global reg; B2004FLF4BSH01 SD Series Continuous-Duty Type TKKH AC Motor, Totally Enclosed Fan Cooled Enclosure, 200 hp, 460 VAC, 60 Hz, 3 ph Phase, 447T Frame, 1800 rpm Speed, Footed Mount
AC Motors
7044672
B2004FLF4BSH01
Toshiba
$0.00
/ ea
Toshiba EQP Global® AC Motor, Continuous-Duty Type TKKH, Series: SD Series, General Purpose AC Motors, Compressor Motors, Fan & Blower Motors Application, 200 hp, 460 VAC, 232 A, 60 Hz Frequency, 3 ph ph, 1800 rpm Speed, Totally Enclosed Fan Cooled Enclosure, 447T Frame, 3-3/8 in Shaft, CW/CCW Rotation, 1.15 Service Factor, Ball/Roller Bearing, 590 ft-lb Torque, Footed Mounting, 40 deg C, Insulation Class: Class F, Cast Iron, 20:1 Constant Torque Speed, 60:1 Variable Torque Speed, 52.2 in L x 25.6 in H Dimensions
- Features
- IP55 protection
- Cast iron frame, brackets and conduit box
- Oversized 300 series bearing on all frames
- No-load commercial testing on all motors
