Toshiba 0604SDSR41B-P

Toshiba EQP Global reg; 0604SDSR41B-P SD Series Continuous-Duty Type TKKH AC Motor, Totally Enclosed Fan Cooled Enclosure, 60 hp, 230/460 VAC, 60 Hz, 3 ph Phase, 364TS Frame, 1800 rpm Speed, Footed Mount
AC Motors
7359984 0604SDSR41B-P
Toshiba
$0.00 / ea

Toshiba 0604SDSR41B-P
Toshiba EQP Global® AC Motor, Continuous-Duty Type TKKH, Series: SD Series, General Purpose AC Motors, Compressor Motors, Fan & Blower Motors Application, 60 hp, 230/460 VAC, 138/69 A, 60 Hz Frequency, 3 ph ph, 1800 rpm Speed, Totally Enclosed Fan Cooled Enclosure, 364TS Frame, 1-7/8 in Shaft, CW/CCW Rotation, 1.15 Service Factor, Ball Bearing, 178 ft-lb Torque, Footed Mounting, 40 deg C, Insulation Class: Class F, Cast Iron, 20:1 Constant Torque Speed, 60:1 Variable Torque Speed, 30.9 in L x 21.2 in H Dimensions
QTY
Add to Wishlist
  • Features
  • IP55 protection
  • Cast iron frame, brackets and conduit box
  • Oversized 300 series bearing on all frames
  • No-load commercial testing on all motors
