Legrand PS430B5S
Pass & Seymour PS430B5-S 3-Phase Splashproof Pin and Sleeve Inlet, 600 VAC, 30 A, 3 Poles, 4 Wires, Gray
Pin and Sleeve Devices
7317266
PS430B5S
Legrand
$0.00
/ ea
"Three pole, Four wire, Pin and Sleeve Inlet. 30 amp, 3/600 volt.
- Features
- All Pass & Seymour® watertight pin and sleeve plugs, connectors, receptacles and inlets bring you the features to enhance versatility, reliability and safety
- North American products come completely ready to wire, for quick, simple installation
- All feature chemical-resistant thermoplastic construction
- Shrouded, nickel plated, solid brass pins provide corrosion protection and excellent conductivity
- An exclusive, hinged cord-grip eliminates loose parts that get lost
- 3000 VAC maximum dielectric voltage withstand voltage
- Polyamide 6 contact carrier and mounting flange, polyamide 66 locking ring, neoprene mounting and sealing gasket, brass pins, zinc plated steel terminal screws material
- 30 deg C maximum temperature rise
- Clock position 6 configuration
- Impact, chemical resistant, non-conductive retaining screw, brass male/female contacts
