Woodhead 26W75BLK
Woodhead reg; 26W75BLK 130147 Male Locking Plug With Locking Blade, 250 VAC, 20 A, 3 Poles, 4 Wires, Black
Plugs Connectors
6814645
26W75BLK
Woodhead
$0.00
/ ea
- Amperage Rating: 20
- Color: Black
- Cord Diameter: 3/4
- Enclosure: IP67
- Material: Rubber
- Nema Rating: NEMA L15-20
- Number of Poles: 3
- Number Of Wires: 4
- Series: 130147
- Temperature Rating: -40 to 75
- terminal type: Screw/Wire
- Type: Male
- Voltage Rating: 250
Woodhead® Locking Plug, Male, Series: 130147, 250 VAC, 20 A, 3 Pole, 4 Wires, NEMA L15-20 NEMA Rating, IP67 Enclosure, 3/4 in Diameter Cord, -40 to 75 deg C, Screw/Wire Terminal, Rubber, Black
- Features
- Multiple seal plug/connector interface keeps out contaminants, resists vapour and water from high pressure wash down up to 1000 psi
- Color coded 1/4 in terminal screws pre set in open position, ready to wire
- Wire screw terminals are tri-drive to be used with straight blade, Phillips and square-drive screw drivers
- Floating blade construction provides self-alignment, and a better mechanical and electrical connection minimizing wear and heat generation
- Transparent wiring guide to verify all wire strands are in place before securing wire
- Captive, tri-drive head, stainless steel, speed screw provides easy assembly and long life
- Three piece strain relief seals cord without damaging the cord
- Nickel plated brass plug blades and connector contacts
- NEoTEX® paracril OZO rubber outer housing and grommet
- Stainless steel face screws
- Nylon face insert
- Brass wire saddle clamp
- F3 body 3/4 in cord grip
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%
- Lexan receptacle coverplate and closure caps
