Legrand PS420P12W
Pass & Seymour PS420P12-W 3-Phase Watertight Pin and Sleeve Plug, 125/250 VAC, 20 A, 3 Poles, 4 Wires, Black
Pin and Sleeve Devices
6947245
PS420P12W
Legrand
$0.00
/ ea
- Amperage Rating: 20
- Color: Black
- Dimensions: 6.2
- Enclosure: IP67
- Frequency Rating: 60 to 400
- Grade: Commercial
- Horsepower: 1
- Material: Thermoplastic
- Number of Poles: 3
- Number Of Wires: 4
- Temperature Rating: -50 to 80
- terminal type: Screw
- Type: 3-Phase Watertight
- Voltage Rating: 125/250
Three pole, Four wire, Pin and Sleeve Plug, 20 amp, 125/250 volt.
- Features
- All P and S watertight pin and sleeve plugs, connectors, receptacles and inlets bring you the features to enhance versatility, reliability and safety
- North American products come completely ready to wire, for quick, simple installation
- All feature chemical-resistant thermoplastic construction
- Shrouded, nickel plated, solid brass pins provide corrosion protection and excellent conductivity
- An exclusive, hinged cord-grip eliminates loose parts that get lost
- IEC 309-2 clock position 12 configuration
