Legrand PS4100C9W
Pass & Seymour PS4100C9-W 3-Phase Watertight Pin and Sleeve Connector, 250 VAC, 100 A, 3 Poles, 4 Wires, Black
Pin and Sleeve Devices
624007
PS4100C9W
Legrand
$0.00
/ ea
- Amperage Rating: 100
- Color: Black
- Dimensions: 7-1/4
- Enclosure: IP67
- Frequency Rating: 60 to 400
- Grade: Commercial
- Material: Thermoplastic
- Number of Poles: 3
- Number Of Wires: 4
- Temperature Rating: -50 to 80
- terminal type: Screw
- Type: 3-Phase Watertight
- Voltage Rating: 250
Three pole, Four wire, Pin and Sleeve Connector. 100 amp, 3/250 volt.
- Features
- All Pass & Seymour® watertight pin and sleeve plugs, connectors, receptacles and inlets bring you the features to enhance versatility, reliability and safety
- North American products come completely ready to wire, for quick, simple installation
- And all feature chemical-resistant thermoplastic construction
- Shrouded, nickel plated, solid brass pins provide corrosion protection and excellent conductivity
- An exclusive, hinged cord-grip eliminates loose parts that get lost
- 3000 VAC maximum dielectric voltage withstand voltage
- Polyamide 66 cover and cord grip, stainless steel cover spring, neoprene sealing gasket, brass with nickel plate sleeve, zinc plated steel terminal screws, natural rubber grommet, stainless steel cord-grip screws and assembly screws material
- 30 deg C temperature rise
- 9 clock position of grounding sleeve
- Nylon construction for high impact, combination head screws, rating compliance visible
- 2 AWG wire size
