Eaton Bussmann Inc. HBW-M
Bussmann HBW-M Fuse Holder, 250 VAC, 6.3/12/16 A, 1 Poles
Fuse Holders and Blocks
7578851
HBW-M
Eaton Bussmann Inc.
$0.00
/ ea
- Amperage Rating: 6.3/12/16
- Color: Black
- Connection Type: Kicked
- Fuse Diameter: 5
- Fuse Length: 20
- Material: Thermoplastic
- Mounting Type: Vertical PC Board
- Number of Poles: 1
- Series: HBW
- Temperature Rating: -40 to 85
- Voltage Rating: 250
Bussmann Fuse Holder, Series: HBW, 250 VAC, 6.3/12/16 A, 1 Pole, Kicked, Vertical PC Board Mount, 20 mm Fuse Length, 5 mm Fuse Dia, -40 to 85 deg C, Thermoplastic, Black
- Features
- Fuse carriers are interchangeable
- Fuse carrier and knob are spring loaded bayonet type with screwdriver slot
- Kicked terminals for optimum wave soldering
- High dielectric molded thermoplastic meets ul 94V0 flammability rating
- 16 A for UL, 12 A for CSA, 6.3 A for VDE
- Without stability pins
