Panduit PUR6004GR-UY
Panduit PUR6004GR-UY TX6000 Enhanced Type CMR Cat 6 UTP Riser Cable, Reel-In-Box Packaging, 80 VAC, (4 Pairs) 23 AWG Bare Copper Conductor, 1000 ft L
Category 6 Cable
7290536
PUR6004GR-UY
Panduit
$0.00
/ ft
- Conductor size: 23
- Conductor Type: Bare Copper
- Insulation Material: Polyolefin
- Jacket Color: Green
- Jacket Material: PVC
- Length: 1000
- Number of Conductors: 4 Pairs
- Outside Diameter: 0.243
- Packaging Type: Reel-In-Box
- Series: TX6000™ Enhanced
- Temperature Rating: -4 to 167
- Type: Type CMR Cat 6 UTP
- Voltage Rating: 80
The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), Green jacket. Packaged 1000 ft./305m on a reel in a box.
- Features
- Descending length cable markings enable easy identification of remaining cable which reduces installation time and cable scrap
- Cable supplied in an easy payout reel-in-a-box
- Twisted in pairs, separated by an integrated pair divider, and protected by a low smoke
- 25 lbf (110 N) maximum installation tension
